Brakelight Assembly (Arctic Cat 90 2T)
Change Assembly
| # | Product Name | Req'd | Price: | |
|---|---|---|---|---|
| 1 |
Bracket, Brakelight
3301-213
|
$6.97 | ||
| 2 |
Brakelight Assembly | (Inc. 3-6)
3301-148
|
|||
| 3 |
Bulb, Brakelight
3301-150
|
|||
| 4 |
Screw, Machine
3301-314
|
$0.70 | ||
| 5 |
Base, Brakelight
3301-453
|
|||
| 6 |
Lens, Brakelight
3301-452
|
|||
| 7 |
Flag/Spring Assembly | (Inc. 8-9)
3301-274
|
|||
| 8 |
Flag
3301-464
|
|||
| 9 |
Spring, Flag
3301-273
|
|||
| 10 |
Screw, Cap
3301-490
|
$1.39 | ||
| 11 |
Washer
3301-472
|
|||
| 12 |
Screw, Cap
3301-386
|
|||
| 13 |
Washer
3301-338
|
$0.42 | ||
| 14 |
Nut, Flange
3301-327
|
